Product Center
| Items | Standard | |
| Operating temperature range | -30℃ to +85℃ | |
| Electrical performance | Rating | 50mA. 12V DC |
| Insulation resistance | 100MΩ min. 100V DC | |
| Dielectric strength | 250V AC for 1 min. | |
| Contact resistance | 100mΩ max. | |
| Durability | Lifetime | B=300,000Cycles C=100,000Cycles |
| Mechanical performance | Operating force | B:180gf C:250gf |
| Travel | 0.2±0.1mm | |
